ABIS Mold Technology Co., Ltd. is one of the leading manufacturers and suppliers of metal injection molding (mim) of gear medical in China. Please feel free to buy high quality metal injection molding (mim) of gear medical made in China here from our factory. Welcome to view our website for more information.
Product description:
Metal injection molding (MIM) is a high-tech near net shaping process to mass-produce small metal parts with complex shape, high precision and good performance. We have accumulated twenty years of experience with tools designing and machining, self-binder system and advanced debinding-sintering furnace
Characteristics:
More homogeneous microstructure, higher density between 95%-100% of theoretical density
Surface without polishing better than Ra. 1.0 tolerance without rework can be 0.3%-0.5% of blueprint dimensions
Consistent quality and high production efficiency, raw materials can be reused in mass production, costs can be sharply reduced
Applications:
Medical, Automotive, IT, Mechanical, Consumer applications
| Materials | Density | Rockwell Hardness | Tensile Strength | Elongation | |
| g/cm3 | Rockwell | MPa | % | ||
| Iron-base alloy | MIM-2200(S) | 7.65 | 45HRB | 290 | 40 |
| MIM-2200(HT) | 7.65 | 50HRC | 380 | 20 | |
| MIM-2700(S) | 7.65 | 69HRB | 440 | 26 | |
| MIM-2700(Carbonitriding) | 7.65 | 55HRC | 830 | 9 | |
| MIM-4650(S) | 7.55 | 90HRB | 700 | 11 | |
| MIM-4650(HT) | 7.55 | 48HRC | 1655 | 2 | |
| MIM-8620(S) | 7.5 | 85HRB | 445 | 20 | |
| MIM-8650(HT) | 7.5 | 35HRC | 800-1300 | 5-9 | |
| Stainless Steel | MIM-316L(S) | 7.8 | 67HRB | 520 | 50 |
| MIM-304L(S) | 7.75 | 60HRB | 500 | 70 | |
| MIM-17-4PH(S) | 7.6 | 30HRC | 900 | 6 | |
| MIM-17-4PH(HT) | 7.6 | 40HRC | 1185 | 5 | |
| MIM-440C(S) | 7.5 | 45HRC | 700 | 15 | |
| MIM-430(S) | 7.5 | 65HRB | 410 | 25 | |
| MIM-420 (HT) | 7.25 | 45HRC | 900 | 6 | |
| MIM-410(HT) | 7.25 | 40HRC | 900 | 7 | |
| Tool steel | M2(S) | 7.9 | 60HRC | ||
| M2(S) | 7.9 | 63HRC | |||
| S7(S) | 7.2 | 45HRC | 1550 | 3 | |
| S7(HT) | 7.2 | 59HRC | 1850 | 2 | |
| Soft magnetic alloy | FeSi3 | 7.5 | |||
| Tungsten alloy | 95%W-Ni-Fe | 18.1 | 30 | 960 | 25 |
| 97%W-Ni-Fe | 18.5 | 33 | 940 | 15 | |
| Hard metal alloy | YG8X | 14.9 | HRA90 | Banged Strength 2300 |
